APPLICATION
Mainly used in electric vehicle PDU, DC / DC, PTC, oil pump, air pump.
CHARACTERISTIC
Easy installation, reliable connection and convenient disassembly. Using plastic shells , low cost and high output.
Built-in high-voltage interlock function, with double level linkage interlock structure, limited protection of automobile high-voltage circuit. Various foolproof key positions can be selected.
|
Mechanical characteristics |
|
||||||
|
Electrical characteristics |
|
||||||
|
Environmental performance |
|
|
Product selection table |
||||||
|
Wire diameter / key position |
A | B | C | D | E |
Remarks |
| 2.5mm2 | DH1-2P28-A025 | DH1-2P28-B025 | DH1-2P28-C025 |
DH1-2P28-D025 |
DH1-2P28-E025 |
Plug |
| DH1-2R28-A025 | DH1-2R28-B025 | DH1-2R28-C025 |
DH1-2R28-D025 |
DH1-2R28-E025 |
Socket |
|
| 4mm2 | DH1-2P28-A04 | DH1-2P28-B04 | DH1-2P28-C04 |
DH1-2P28-D04 |
DH1-2P28-E04 |
Plug |
| DH1-2R28-A04 | DH1-2R28-B04 | DH1-2R28-C04 | DH1-2R28-D04 | DH1-2R28-E04 | Socket | |
