| Technical specifications |
| 1. Installation method: stake-type / wall-mounted |
| 2. Maximum power: 7KW |
| 3. Communication interface: GPRS/WIFI (optional) |
| 4. Outdoor protection: IP55 |
| 5. Safety specifications: Conforms to IEC 61851 and IEC 62196 standards and the latest GB/T 18487 and GB/T 20234 standards |
| 6. Operating temperature: ambient temperature -30°C to 50°C |
|
| Output type |
| 1. GB/T 18487-2015 mode 3 |
| 2. IEC 61851 Type 2 / Type 3 |
| 3. 7KW：220VAC@32A |
|
| Basic skills |
| 1. Start method: plug and charge, RFID card |
| 2. Remind function: charge indication, fault indication |
| 3. Self-test function: fault self-positioning |
| 4. Human-computer interaction: LED display (optional) |
|
| Security |
| 1. Leakage detection and protection |
| 2. Emergency stop button protection |
| 3. Over-current, over-voltage, under-voltage, over-temperature protection |
| 4. Power failure data records |
| 5. Surge protection meets latest IEC 61851 & GB/T 18487 standards |
| 6. Electromagnetic compatibility complies with the latest IEC 61851 & GB/T 18487 standards |
|
