| Features |
| 1. Meet GB/T 20234.2-2015 regulations and requirements |
| 2. Nice appearance，hand-held ergonomic design，easy plug |
| 3. Safety pins insulated head design to prevent accidental diirecrt contact with staff |
| 4. Excellent protection performance,protection grade IP55(working condition) |
|
| Mechanical properties |
| 1. Mechanical life : no-load plug in/pull out＞10000 times |
| 2. Impat of external force: can afford 1m drop and 2t vehicle run over pressure |
|
| Electrical Performance |
| 1. Rated current：16A/32A |
| 2. Operation voltage： 250V |
| 3. Insulation resistance：＞100MΩ（DC1000V） |
| 4. Terminal temperature rise：＜50K |
| 5. Withstand Voltage ：2000VAC/1min |
| 6. Contact Resistance： 0.5mΩ Max |
|
| Applied Materials |
| 1. Case Material: Thermoplastic,flame retardant grade UL94 V-0 |
| 2. Pin：Copper alloy,silver + thermoplastic on the top |
|
| Environmental performance |
| 1. Operating temperature：-30℃～+50℃ |
|
